If the spoke broke somewhere in the middle it will be a little tougher to get an accurate measurement. The best way that I've found to do this is to measure a different spoke on the same side of hub using a soft measuring tape, measuring from the head of the spoke to the end of the nipple and then adding 10mm. Also asked, how are spokes measured?
Spoke length is measured from the inside of the elbow, as shown in the image below, to the threaded end. When measuring a spoke using a tape measure, a second spoke may be used to hold the elbow of the spoke and the tape measure's tab, as shown.
Also, can you ride a bicycle with a broken spoke? 7 Answers. Yes you can ride home with a broken spoke. I'd probably unscrew the spoke from the nipple before doing so, so that it doesn't wobble around and get caught in other bits of the bike. Bike wheels are wonderful things that can easily put up with having a few spokes missing.
Besides, can you fix a snapped spoke?
If the spoke's snapped inside or near the nipple, replace it. Thread a new one onto the end of a spoke, feed it through the hole and then unscrew the nipple from the spoke.
What size are my bike spokes?
To check which size your spokes are, try to thread one into a 1.8mm nipple. If it doesn't go, it's a 2.0mm. NOTE: These sizes have nothing to do with spoke wrench sizes. WARNING: If you use 1.8mm spokes and 2.0mm nipples, the threads will strip out of the nipples once you tension the spoke.
Related Question Answers
How do you know what size spoke nipples to get?
The best method to determine the correct spoke wrench size is to use a caliper and measure the nipple across the wrench flats. It is important to know that the diameter, or so called “gauge”, of the spoke does not determine the spoke wrench size. How is ERD measured?
Measure the length of a nipple (dimension B in the figure) and add it twice (once for each nipple). The result is Effective Rim Diameter (ERD). Thus, ERD = A + 2B. What are the best spokes?
There are three top makes of spokes - Sapim, DT and Wheelsmith. They are all so equal that it's immaterial which one you pic. Of their models, Sapim Race, DT Competition and Wheelsmith DB14 are the "best" ones for you. What are straight pull spokes?
' Straight-pull spoke: spokes that have no bend at the flared head, or in the case of DT Swiss Tricon wheels, spokes that are threaded at both ends. Straight-pull spokes require dedicated hubs. How do you measure hub size?
To correctly measure the bolt circle of a hub, measure from the center of the hub to the center of a stud and multiple that measurement by two. The second specification to determine is the Inner and Outer bearing size. What are sapim spokes?
Being the link between the hub and the rim, the spoke has multiple functions: Carry: spokes carry the weight of the bicycle as well as it load. Absorb: spokes absorb the irregularities of the road and ensure the comfort of the rider. Transmission: spokes transmit acceleration and braking effort of the rider. How do I know what size my bike hub is?
Here's how to measure these distances: - Figure out the distance between the lock nuts (where the hub sits in the dropouts) - 100 or 110 mm is typical for the front.
- Take that number and divide by 2.
- Then measure from the flange to the lock nut.
What is a spoke wrench used for?
A bicycle spoke wrench is used to adjust wheel spokes in order to “true” a wheel—that is, put it back into alignment. It's also used when installing a new spoke. Each spoke is secured to the wheel rim by a spoke nipple, which can be turned to either tighten or loosen the spoke's tension. What causes broken spokes?
Bike spokes break most commonly due to wear and tear. A high-frequent cause for spoke breaks is that the rider has hit a curb or pothole, doesn't maintain the bike well, or the passenger is too heavy for that model. Rougher terrain will also deteriorate the rims faster, which in turn deteriorates the spokes faster. How much does it cost to replace a spoke?
Spokes are usually $1.00 - $2.00 each. Any shop will sell individual spokes. Labor to replace a spoke is $10 - $20 depending on your location. What is a spoke?
A spoke is one of some number of rods radiating from the center of a wheel (the hub where the axle connects), connecting the hub with the round traction surface. Do you need a spoke guard?
No. It does no harm and may save your wheel from damage. Only if you don't know how to tune your derailleur. This is one of those things where if you have to ask you should leave it on. What happens if a bike spoke breaks?
The wheel won't be 'true' anymore. This means it is misaligned and won't turn completely at a straight aligned angle with your brakes and the rest of your bike. It will rub against the brake pads unevenly, causing damage to both the wheel and brakes. What does broken spokes really mean?
Generally, repeated issues with broken spokes indicates either damage to the rim, meaning that the metal hoop of the rim is physically bent while under no tension, or that the spokes are at the end of their fatigue life. Are loose spokes dangerous?
Never ride with a loose spoke. The friction created will cause the rider to burst into flames and may even cause the Earth to slip off it's axis. A wheel with so few spokes, and has a loose spoke, AND is still true, has major problems. How often do bike spokes break?
You may break a spoke with these wheels every 5 or 6000 miles, but that's not because the spokes wear out. And that seems fairly frequent to breaking spokes on average, especially for a rider of your weight. There would have to be something going on with the spoke or wheel to cause it to break. Can you ride a mountain bike missing a spoke?
Riding with a missing spoke will put more stress on the other spokes and the rim, how much extra stress depends on the rim and how many spokes. I wouldn't do it, it's an easy fix now that will only get harder if you ride it while damaged. How do you prevent broken spokes?
The best way to avoid spoke fatigue is to go to a skilled builder, who will advise on spoke count and rim weight (heavier rims are stronger…) and use correct spoke tension and proven stress-relieving techniques to minimise the cyclic loading responsible for fatigue failure. What happens if your spokes are loose?
If your spokes are so loose they rattle, they're providing virtually no strength to the wheel structure. It's no better than if that spoke were missing or broken. It's a big indicator that your bike wheels need truing. Is it safe to ride a bike with a wobbly wheel?
An unbalanced mass rotating at high speed can cause a significant amount of wobble. And either will make the bike harder to handle at high speeds (especially those 50mph downhills). In theory, an out-of-true wheel probably affects spoke life, and a wheel, once out-of-true, will tend to get worse over time. Why do bike spokes get loose?
Since the spokes of a properly built wheel are under a high level of tension, there is no "play" in the threads. For the spokes to loosen, the load would have to deform the rim enough to relieve the spoke of all tension so that the nipple can turn. What are the strongest bicycle spokes?
Dt-swiss alpine 3 spokes are about the strongest to price ratio i know,sapim are stronger but you pay for it. Brass nipples add about 20% more strength for a small increase in weight,going to 36 spokes adds 15% more strength with a little added weight too. How are BMX spokes measured?
An easy way to measure this is to measure from the cone nut to the centre of your flange, and then take that and subtract it from 55. (Standard cone to cone with on a hub is 110mm) If your hub has two different size flanges, you need this measurement for each side. 4. Hub Spoke hole diameter: Just leave this as 2.5.
