The way how I did it is that I push the clip, wriggle the connector from side to side, then pull out the connector. If the connector won't come out, push the clip and wriggle some more. Make sure you are pushing the clip the whole time. Furthermore, why is there a pin missing on my 24 pin connector?
This empty pin on your 24 pin connector used to be home to a wire carrying -5V. Since around 2003 the -5V rail was removed from ATX specification and as a result most modern power supplies do not include it.
Likewise, what does the 24 pin connector do? Print
| Name(s) | Function |
| 24 Pin 20+4 Pin | Main power connector for the motherboard. Notes: On a 20+4 Pin connector, four of the pins are on a separate block making it reverse compatible with the older motherboards that require only a 20 pin connector. |
Consequently, how do you fix a 24 pin connector?
You can't readily push the pin back in when it's plugged in, but what you can do is unplug the entire cable, then push the pin back into place. They should latch into place (there are little latches on either side of the pins). Then you should be able to reconnect the cable to the motherboard.
What does the 24 pin connector power?
It connects a power supply to an ATX style motherboard. A power supply with a 24-pin connector can be used on a motherboard with a 20-pin connector by leaving the four additional pins disconnected. However, if you have a 24-pin connection on your motherboard all 24-pins need to be connected.
Related Question Answers
Why will my PC not turn on?
Unplug your computer and plug it directly into a wall outlet you know is working, rather than a power strip or battery backup that may be failing. Make sure the power switch on the back of your power supply is flipped on, and if the outlet is connected to a light switch, make sure that switch is turned on too. How can I test my PSU?
How to: Test a power supply unit - Shut off your PSU.
- Unplug all cables from the PSU except for the main AC cable and the 24-pin cable.
- Locate pin 4 and pin 5 on your 24-pin cable.
- Bend your paper clip so the ends can be inserted into pin 4 and pin 5.
- Turn on the PSU.
- See if the PSU fan turns.
How do you do a PSU paper clip test?
Bend the paperclip and insert one end into the green pin (PS_ON) and the other into any of the black pins (Ground). Flip the switch at the rear of the PSU, and listen for the internal fan. If you can hear the fan, this should verify the power supply is turned on. What is the 4 pin ATX power connector for on a motherboard?
The ATX 4-pin power supply connector is a standard motherboard power connector used to provide +12 VDC to the processor voltage regulator. How do I remove the motherboard power supply connector?
Distinguished. There's a little tab on the plastic connector that must be pinched in order to remove the cable from the board. It should be on the outside-facing side of the connector (towards the outside edge of the board). Squeeze/pinch that, and gently pull on the plastic connector - not the wires. How do I connect my 4 pin PSU to 8 pin motherboard?
The 8-pin connector is literally designed as two of the 4-pin connectors put together. It is entirely possible to just plug the 4-pin connector in the 8-pin slot. It won't damage anything, but the motherboard will detect the difference and either not start up at all, or run in a VERY restricted mode. What is EATX power connector?
EATX refers to the motherboard. EXTENDED ATX. There is no "EATX" power standard. EATX, ATX, micro ATX, etc. all use ATX 24-pin power connectors. How many pins does an ATX power connector have?
24
Is it hard to replace a power supply?
Upgrading your graphics card can also push your PC's power supply past its limits, depending on the model. But fear not. Replacing a power supply is a surprisingly easy process. Is it easy to replace a power supply?
You can't repair your desktop PC's power supply, you can only replace it. Don't ever open your computer's power supply or try to fix it yourself. Remember — replace, don't try to repair. The power supply stores powerful jolts of electricity, even when the computer is turned off and unplugged. How long do PSU last?
five years
When should I replace my PC power supply?
Honestly that depends on how much you use the PC, and what brand the power supply is. If you're running a 24/7 bitcoin mining machine that is constantly at 800W on your 850W power supply. Then change it every 2–4 years. If you just have a home PC that is used for occasional gaming, every 5–8 years should be sufficient.
